SB25-BA

SWITCH PUSH DPDT 15A 125V

SB Series
SWITCH PUSH DPDT 15A 125V

Image for reference only. Please see product specifications.
Not recommended for new designs.
General Specifications
Part No.
SB25-BA
Description
SWITCH PUSH DPDT 15A 125V
Name
Pushbutton
Series
SB
Poles
DPDT
Circuits
On-On
Current Rating
15A (AC)
Rating (AC)
125V
Actuator Type
Round, Button
Actuator Cap Color
Black
Mounting Type
Panel Mount, Rear
Termination Style
Solder Lug
panel cutout dimensions
Circular - 12.50mm Dia
Rating
15
Illumination
Non-Illuminated
