MN32TXW30

Bracket PC Mount Miniature Rocker

M Series
Bracket PC Mount Miniature Rocker

Image for reference only. Please see product specifications.
3D CAD Model Download Specifications Custom Assembly Check Inventory Sample Request Form Environmental Compliance Product Change Notices

Support Documentation

Standards & Approvals Product Training Modules Processing Data - PDF Electrical Ratings - PDF Lamps and LEDs - PDF
General Specifications
Part No.
MN32TXW30
Description
Bracket PC Mount Miniature Rocker
Name
Rockers
Series
M
Status
Active
Poles
3PDT
Circuits
On-On
Current Rating
4A (AC), 3A (DC)
Rating (AC)
125V
Rating (DC)
30V
Actuator Type
Actuator Arm, Cap Required
Actuator Marking
Varies by Cap
illumination color
0
illumination voltage
0
Mounting Type
Through Hole, Right Angle
Termination Style
PC Pin
Features
Epoxy Sealed Terminals
Rating
6
Illumination
Non-Illuminated
